PM Designer Operation Manual
3-49
CHAPTER 3 CREATING PANEL APPLICATIONS
Property Description
Synchronize Panel
with PLC Select this option so the panel will read time and date information from the
specified variable and adjust its clock accordingly.
Time/date Data Type Specifies the data type for the input time and data information. For details, see the
description of the Time/date Data Type field of the Write group.
Read Address Specifies the variable that the panel will read the time and date information.
Do not run panel
application until the
restart synchronization
is done successfully The password keypad will close automatically when it gets no input from the
operator for the specified time.
Timed When this item is selected, the panel reads time and date information from the
specified variable periodically at a rate specified in the Interval field. You can
specify an interval between 1 and 255 minutes.
Read
Read
Operation
Triggered When this item is selected, the panel reads time and date information from the
specified variable whenever the specified trigger bit changes from Off to On.
Increase Hour Select this option so you can increase the panel's clock by one by changing the
specified trigger bit from Off to On.
Decrease Hour Select this option so you can decrease the panel's clock by one by changing the
specified trigger bit from Off to On.
