PM Designer Operation Manual
12-9
CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
The following table describes each property in the General page.
Property Description
ID The object’s identifier. It is generated when the object is created and is
unchangeable. The identifier is unique within the screen where the object is on.
The format of the ID’s for the historic data tables is HDDnnnn.
Note You can type a note for the object.
Shape settings For details about the following properties, Section 4.3.1.4 Setting up the Shape of
an Object. , Border Color, BG Color
Data Logger Select the data logger whose collected data is to be displayed by the object.
Title Select this option if you want the object to display a title row.
Language Select a language so you can view and edit the settings of the title row for that
language.
Font Select a font for the title text.
Color Select a color for the title text.
Date Specifies the title for the Date column.
Time Specifies the title for the Time column.
Title
Background Color Select a color for the background of the title row.
Vertical Check this option if you want the object to have vertical grids.
Horizontal Check this option if you want the object to have horizontal grids.
Grid
Color Select a color for the grids.
Font Select a font for displaying data.
Default Color Select a color as the default color for displaying data.
Data
Set Default Color to
All Data Items Click this button to set the colors of all the data items to the Default Color.
Date Check this option if you want the object to display the Date column. You need to
select a format for displaying the date. Time/Date
Display
Time Check this option if you want the object to display the Time column. You need to
select a format for displaying the time.
Line Spacing Specifies the extra space in pixels for two adjacent rows in the table.
Item Spacing Specifies the extra space for every column in the table.
