PM Designer Operation Manual
3-46
CHAPTER 3 CREATING PANEL APPLICATIONS
You can request the panel to perform the following file operations using the general command and the specified filename:
Operation
Parameter One Register
(Operation code)
Parameter Two
Register (Data ID)
Parameter Three Register
(Specified filename)
Save logged data to
TXT file
31
ID of the data
logger (0~15)
Specifies the address in the internal
memory $U that stores the specified
filename or full pathname. The name
must be a valid Windows pathname
with ASCII characters only. The
character string must be null
terminated and each character
occupies one byte. The maximum
length of the string is 127. All the
folders stated in the full pathname
must already exist or the file operation
will fail. For example, if the number
stored in this register is 400, it means
the specified filename is stored in
$U400.
Save logged alarms
to TXT file
32
(Not required)
Same as above
Save alarm counts to
TXT file
33
(Not required)
Same as above
Save recipe data to
TXT file
34
ID of the recipe
block (0~15)
Same as above
Save recipe data to
DAT file
35
ID of the recipe
block (0~15)
Same as above
Save logged
operations to TXT file
39
(Not required)
Same as above
Save logged data to
LDF file
40
ID of the data
logger (0~15)
Same as above
Take picture and save
it to BMP file
42
ID of the USB
camera (0~3)
Same as above
Take picture and save
it to JPG file
43
ID of the USB
camera (0~3)
Same as above
