12
PM Designer Operation Manual
12-12
CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
12.3.2. Operation Options
The following operation option can be added to a historic trend graph. Select and set the option in the Historic Trend Graph
dialog box.
Options Description
Visibility
Control You can show and hide a historic trend graph by a specified bit or the current user level. Select and
set this option in the Visibility page.
12.3.3. Settings
You can set up a historic trend graph with the Historic Trend Graph dialog box. There are three ways to open the dialog
box of an object:
1) Double-click the object.
2) Right-click the object to bring up the Object pop-up menu. Select Properties in the pop-up menu.
3) In the Object List window, double-click the row that shows the information of the object.
The Historic Trend Graph dialog box contains the following four pages:
■ General
Described in Section 12.3.4.
■ Curve
Described in Section 12.3.5.
■ Axis
Described in Section 12.3.6 .
■ Visibility
Described in Section 4.3.4.
