Property Description
Monitor
Address Specifies the variable to be monitored.
Click to enter an address for this field. Click to select a tag for this field.
Dynamic
Range Check this option so the minimum and the maximum of the monitored variable will be specified at
runtime. When this option is selected, the minimum and maximum of the marks for the scale of the
circular bar graph can be specified at runtime too. The data that specifies the above two ranges
should be set and arranged correctly in a memory block called the dynamic range parameter block.
You need to specify the dynamic range parameter block for the circular bar graph in the Dynamic
Range Parameter Block field.
Dynamic
Range
Parameter
Block Specifies the variable that stores the dynamic range parameter block for the circular bar graph
when the Dynamic Range is selected. Click to enter an address for this field. Click to
select a tag for this field.
The following table shows the content of the parameter block when the data type is 16-bit and the
scale of the circular bar graph is not dynamic.
Word Parameter
0 The minimum of the monitored variable
1 The maximum of the monitored variable
The following table shows the content of the parameter block when the data type is 16-bit and the
scale of the circular bar graph is dynamic.
Word Parameter
0 The minimum of the monitored variable
1 The maximum of the monitored variable
2, 3 The minimum of the mark for the scale; 32-bit integer number
4, 5 The maximum of the mark for the scale; 32-bit integer number
The following table shows the content of the parameter block when the data type is 32-bit and the
scale of the circular bar graph is not dynamic.
Word Parameter
0, 1 The minimum of the monitored variable
2, 3 The maximum of the monitored variable
The following table shows the content of the parameter block when the data type is 32-bit and the
scale of the circular bar graph is dynamic.
Word Parameter
0, 1 The minimum of the monitored variable
2, 3 The maximum of the monitored variable
4, 5 The minimum of the mark for the scale; 32-bit integer number
6, 7 The maximum of the mark for the scale; 32-bit integer number
Min. Specifies the minimum of the monitored variable when the Dynamic Range is not selected.
Max. Specifies the maximum of the monitored variable when the Dynamic Range is not selected.
Bar Pattern Select a pattern for the circular bar graph. The pattern will be used to fill the arc/circular strip of the
circular bar graph. When the pattern is filled in the circular bar graph, the black part of the pattern is
painted with the color specified in the Bar FG Color field and the white part of the pattern is painted
with the color specified in the Bar BG Color field.
Bar FG Color Select a color for painting the black part of the specified pattern.
Bar BG Color Select a color for painting the white part of the specified pattern.
Back Color Select a color as the background color for the arc/circular strip of the circular bar graph.
