10
PM Designer Operation Manual
10-8
CHAPTER 10 RECIPES AND RECIPE OBJECTS
Property Description
Current Recipe The address range of the internal memory in the panel that the current recipe locates.
Range Type Address Format Description
Bit Address Range $CRm:n.b
b: 0~f Each bit address in the range
refers to a bit of a recipe word in
the current recipe of the specified
recipe block.
Word Address Range $CRm:n Each word address in the range
refers to a recipe word in the
current recipe of the specified
recipe block.
Current Recipe
Number Register $RNm An internal register of the panel
that specifies the current recipe
number of the specified recipe
block.
Legend: m = Recipe Block ID; n = The Number of Recipe Word, b = Bit Number;
Need space in flash ROM to
save backup Check this option if you need the space in flash ROM to save the backup recipes.
Do not use battery backed
RAM Check this option so the memory of the recipes will be located in ordinary RAM and
the recipe memory will be cleared whenever the target panel is powered up. If this
option is not selected, the memory of the recipes will be located in the battery backed
RAM. The recipe data will not be lost after power down if the battery backed RAM is
used for the recipes.
