4
PM Designer Operation Manual
4-46
CHAPTER 4 DESIGNING SCREENS
4.3.1.6. Text Settings
This section describes how to set up the text of the inner label for the following types of objects:
Multi-state Switch, Radio Button Group, Step Button, Page Selector, Multi-state Lamp, Message Display, and
Day-of-week Display.
The property sheets of the above mentioned objects provide you the Text page to set up the text of the inner label. The
following is an example of the Text page.
The following table describes each property in the Text page.
Property Description
Language The language that you are setting the text for.
Border Spacing The margin (in pixels) to the border of the object’s shape for the text body.
Use the text of the
first language for all
other languages
Check this item so the inner label always shows the text of the first language regardless of
what the current language is.
Move Up Click this button to move the current text (and picture) up in the list and thus the associated
state number of the current text (and picture) is decreased by one.
Move Down Click this button to move the current text (and picture) down in the list and thus the associated
state number of the current text (and picture) is increased by one.
Continued
