PM Designer Operation Manual
2-18
CHAPTER 2 CREATING PROJECTS
2.3.3.1. Tag Group Explorer
Tag explorer displays links, recipes, data loggers and their tag groups if any. From tags explorer, you can:
■ Open a tag group of a link for editing by clicking the node
■ Import and export tags of a link
Described in
Section 2.3.4
■ Add new groups to a link and delete or rename the existing tag groups
Described in
Section 2.3.5
■ View tags (Data Items) of recipes and data loggers.
If there are any recipes or data loggers in the application, the tag editor will display their data items as the tags. All the
data items (tags) for the recipes or data loggers are read only in the tag editor. If you want to edit the data items (tags),
please use the corresponding dialog box.
Recipe Block Name (ID)
Data Logger Name (ID)
You can edit the data items of
the selected recipe block with
the recipe block dialog box.
Please see
Section 10.5
Setting up Recipe Blocks for
details.
