PM Designer Operation Manual
3-19
CHAPTER 3 CREATING PANEL APPLICATIONS
3.3.4. Setting up Internal Memory
You can use the Internal Memory dialog box to define the sizes of the regular user memory and the battery backed user
memory. To open the Internal Memory dialog box, you can do one of followings:
1) In the PM Designer's Project Manager tool window, double-click the Internal Memory Node ( ) in Panel Application
> Links
2) In the PM Designer's Project Manager tool window, right-click the Internal Memory Node ( ) in Panel Application >
Links to bring out the popup menu and select Properties menu item.
The following is an example of the Internal Memory dialog box.
Specify the size of regular user memory in
word. The size must be between 0 and
131072 words. By default, it is 5000.
Specify the size of battery backed user
memory in word. The size must be between 0
and 131072 words. By default, it is 0.
