PM Designer Operation Manual
5-12
CHAPTER 5 BUTTONS AND SWITCHES
The following table describes each property in the General page.
Property Description
ID
The object’s identifier. It is generated when the object is created. The identifier is unique
within the screen where the object is on and is unchangeable. The format of the ID’s for
screen buttons is SB####.
Note You can type a note for the object.
Shape settings
For details about the following properties, see Section 4.3.1.4 Setting up the Shape of an
Object. Picture Shape, , VFTA, , Border Color, Pattern, FG Color,
BG Color
External Label
Check this option if you want the object to have an external label. Set up the external label
in the External Label page.
Operation
Specifies the operation that you want the screen button to perform. There are four choices:
Open Screen, Previous Screen, Close and Open Screen, and Close Screen. For details,
see
Section 5.3.1 Basic Operations.
Screen Specifies the screen to be opened.
Box>
Check this option if you want the button to change the current user level.
Change
User Level
New
User
Level
The new user level to replace the current user level.
Acknowledge Alarm
Check this option if you want the button to acknowledge the associated alarm of the screen
where the button is on.
Indicate Screen Already
Opened
Check this option if you want the button to indicate the specified screen is already open.
Macro
Check this option if you want the button to have a macro. Specify and edit the macro in the
Macro page.
Button
Down
Specifies that the touch operation is activated when the button is pushed.
Activation
Button
Up
Specifies that the touch operation is activated when the button is released.
Key
The hard key that is used to operate the object. This item is available only when the target panel has
hard keys.
Continued
