PM Designer Operation Manual
12-30
CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
The following table describes each property in the Axis page.
Property
Description
Show Ticks
Check this option if you want the X axis to have ticks.
Show Y-axis Grid
Select this option if you want the X axis to have vertical grids.
Axis/Tick Color
Select a color for the X axis and its ticks.
Grid Color
Select a color for the vertical grids.
Number of Major
Divisions
The number of major divisions for the X axis. The minimum you can specify is one.
X
Axis
Number of
Sub-divisions
The number of divisions between two adjacent major ticks. The minimum you can
specify is one.
Show Marks
Check this option if you want the major ticks to have marks.
Font
The font of the marks.
Dynamic Range
Check this option if you want the minimum and maximum of the marks to be controlled
by the dynamic range parameter block of the associated object at runtime.
Min.
The minimum of the marks. It is a 32-bit integer.
Max.
The maximum of the marks. It is a 32-bit integer.
Total Digits
The total digits to be displayed for the marks.
Mark
Fractional Digits
The number of fractional digits for the marks. For example, when the Maximum is
5000, the Total Digits is 4, and the Fractional Digits is 2, the mark for the Maximum will
be 50.00.
Show Ticks
Check this option if you want the Y axis to have ticks.
Show X-axis Grid
Select this option if you want the Y axis to have horizontal grids.
Axis/Tick Color
Select a color for the X axis and its ticks.
Grid Color
Select a color for the horizontal grids.
Number of Major
Divisions
The number of major divisions for the Y axis. The minimum you can specify is one.
Y
Axis
Number of
Sub-divisions
The number of divisions between two adjacent major ticks. The minimum you can
specify is one.
Show Marks
Check this option if you want the major ticks to have marks.
Font
The font of the marks.
Dynamic Range
Check this option if you want the minimum and maximum of the marks to be controlled
by the dynamic range parameter block of the associated object at runtime.
Min.
The minimum of the marks. You can specify a 32-bit signed integer.
Max.
The maximum of the marks. You can specify a 32-bit signed integer.
Total Digits
The total digits to be displayed for the marks.
Mark
Fractional Digits
The number of fractional digits for the marks. For example, when the Maximum is
5000, the Total Digits is 4, and the Fractional Digits is 2, the mark for the Maximum will
be 50.00.
