PM Designer Operation Manual
14-29
CHAPTER 14 USING MACROS
STOP_T
Format STOP_T(P1) Data Type U
Function Stops the timer P1.
P1 (C) The ID of the timer.
Example 1 STOP_T( 1 ) /* Stop timer #1 */
WAIT_T
Format WAIT_T(P1) Data Type U
Function Waits for the time-up of timer P1. The macro command following this one will not be executed
until the timer reaches its limit.
P1 (C) The ID of the timer.
Example 1 $U100 = 0 /* Type of operation is One-shot. */
$U101 = 0 /* Initialize the current timer value to 0. */
$U102 = 5 /* Timer limit is 0.5 second (5*100ms). */
$U103 = 0 /* Initialize the time-up flag to 0. */
SET_T( 7 , $U100 ) /* Starts timer #7 as a 0.5 second timer. */
WAIT_T( 7 ) /* Wait 0.5 second */
14.4.10. Keypad Operation
KB_MCR
Format KB_MCR(P1) Data Type U
Function Accepts or ignores the character/command currently input by the associated keypad button. This
command must be used only in a macro that is run by a keypad button. A keypad button runs the
specified macro when it is pressed. You can use this command in a keypad button macro to
accept or ignore the current input of that button.
P1 (I/C) The value or the location that holds the value to determine the acceptance of the keypad button
input. If the value is 0, the input will be accepted; Otherwise the input will be ignored.
Example 1 KB_MCR( 1 ) /* Ignore the current input */
KPD_TEXT
Format KPD_TEXT(P1) Data Type U
Function The memory block (or byte array) that contains the null-terminated ASCII character string to be
used to initialize the keypad display and buffer.
P1 (I) The memory block (or byte array) that contains the null-terminated ASCII character string to be
used to initialize the keypad display and buffer.
Example 1
$U100 = "initial text"
KPD_TEXT( $U100 ) /* Initialize the keypad display and buffer using the string "initial text". */
