PM Designer Operation Manual
3-52
CHAPTER 3 CREATING PANEL APPLICATIONS
3.9.2. Creating and Opening Screens
■ Creating Screens
To create a screen, you can use the following procedures:
1) Do one of the following:
z On the Screen menu, click New Screen…
z In the Project Manager tool window, right-click the panel application > Screens item and then click New Screen…
on the popup menu.
2) In the New Screen dialog box, type the name and number you want, and hit the ENTER key or click the OK button to
validate your choice. The following is an example of the New Screen dialog box.
Note: In each panel application, both the screen name and the screen number have to be unique.
■ Opening Screens
To open a screen, you can do one of the followings:
1) In the Project Manager tool window, double click the screen you want to open
2) On the Screen menu, click Open Screen… In the Open Screen dialog box, select one or multiple screens and click
Open button to open all the selected screens.
The following is an example of Open Screen dialog box.
Specify the screen name here. The screen names are
case insensitive. For example, consider the names
Startup Screen, startup screen to be the same.
Specify the screen number here. The screen number
must be between 1 and 7999.
To select a screen, click the
row of that screen in the list.
To select multiple screens,
click one row and use Ctrl +
Click to add a row to the
selection.
To select continuous screens,
click one row and hold the Shift
key and click the last row.
