4
PM Designer Operation Manual
4-22
CHAPTER 4 DESIGNING SCREENS
The following table describes each property in the General page.
Property Description
Language The language that you are setting the text for.
Shape Check this option if you want the text object to have a frame as its background. The Shape
page appears in the dialog box when the option is selected.
Use the text of the
first language for all
other languages
Check this item so the text object always shows the text of the first language regardless of what
the current language is.
Font
The font of the current text. You can use the drop-down list to select a font. Click to bring
up the Font Templates dialog box and select a font for the current text. You can change the
font templates before selecting a font in that dialog box.
Color The color of the text. To specify the color, click the corresponding Color icon and select a color
from the Color palette.
Transparent Check this item to make the background of the text transparent.
BG Color Specifies the background color of the text. This field is available when the Transparent is not
selected.
Direction Select one of the following directions to arrange the characters of the text.
Direction
From left to
right
From right to
left
From top to
bottom
From bottom to
top
Input text:
An
example
Position
The position of the text body.
The alignment of the text.
Border Spacing The margin (in pixels) to the border of the object’s shape for the text body.
Line Spacing The distance (in pixels) between two adjacent lines of the text.
Character Spacing The distance (in pixels) between two adjacent characters of the text.
