PM Designer Operation Manual
9-21
CHAPTER 9 ANIMATED OBJECTS
Property Description
Marquee Check this option if you want the current picture of the animated graphic to scroll into
both ends of its path. This option is available when the Path Type is Horizontal Line or
Vertical Line.
Duplicate
Picture Check this option so the current picture of the animated graphic will be duplicated by a
specified number of times. All the copies will display and move together. This option is
available when the Marquee option is selected.
Effect
Number of
Copies Specifies how many copies should be made for the Duplicate Picture option.
Monitor Address Specifies the variable that controls the animated graphic.
Click to enter an address for this field. Click to select a tag for this field.
The following table shows the data arrangement of the variable:
Data Type
Settings
16-Bit Unsigned Int.
16-Bit Signed Int.
16-Bit BCD
32-Bit Unsigned Int.
32-Bit Signed Int.
32-Bit BCD
State Control = Dynamic W0 State W0,1 State
Path Type = Dynamic
W0 X
W1 Y
W0,1 X
W2,2 Y
Path Type =
Dynamic; Predefined Positions
W0 Point W0,1 Point
State Control = Dynamic
Path Type = Dynamic
W0 State
W1 X
W2 Y
W0,1 State
W2,3 X
W4,5 Y
State Control = Dynamic
Path Type =
Dynamic; Predefined Positions
W0 State
W1 Point
W0,1 State
W2,3 Point
Data Type The data type of the variable that controls the animated graphic. The supported data
types include: 16-bit Unsigned Integer, 32-bit Unsigned Integer, 16-bit Signed Integer,
32-bit Signed Integer, 16-bit BCD, and 32-bit BCD.
