PM Designer Operation Manual

5-16

CHAPTER 5 BUTTONS AND SWITCHES

Category

Operation

Description

Print Screen

Prints the screen where the button is on. The printed area is specified in the
settings of the screen properties.

Print Screen to File
(256-color .bmp)

Prints the screen where the button is on to a file with the BMP format of 256
colors. The printed area is specified in the settings of the screen properties.

Print Screen to File
(64K-color .bmp)

Prints the screen where the button is on to a file with the BMP format of 64K
colors. The printed area is specified in the settings of the screen properties.

Print Screen to File
(True-color .bmp)

Prints the screen where the button is on to a file with the BMP format. The
color resolution is the same as the target panel’s display. The printed area is
specified in the settings of the screen properties.

Printing
Screen

Print Screen to File
(.jpg)

Prints the screen where the button is on to a file with the JPG format. The
printed area is specified in the settings of the screen properties.

Clear Logged Data

Clears the data of the specified data logger.

Clear Logged Data
(All)

Clears the data of all the data loggers.

Clear Alarm History

Clears the alarm history.

Clear Alarm Counts

Resets the alarm counts to 0.

Clearing
Data

Clear Operation
History

Clears the operation history.

Restart Application

Restarts the application.

Update System and
Application From File
(.prp)

Updates the system programs and the application runtime data from a PRP
file. The original system programs and the application runtime data are
replaced by the new ones.

Running
Application

Boot from File (.prp)

Load-and-runs the system programs and the application runtime data from a
PRP file. The original system programs and runtime data are intact. The
loaded system programs and the runtime data will be lost after power off.

Play Sound

Plays the specified sound file.

Stop Playing Sound

Stops playing the current sound file

Multimedia

Take Picture

Takes a picture from the specified USB camera.

Zoom In

Makes the viewing range of the associated object one half smaller so the
object shows less content with more detail.

Zoom Out

Makes the viewing range of the associated object twice larger so the object
shows more content with less detail.

Adjusting
Viewing
Range

Restore to Normal
View

Restores the viewing range to the original setting.

Scroll Left

Scrolls the content displayed by the associated object to the left.

Scroll Right

Scrolls the content displayed by the associated object to the right.

Scroll Up

Scrolls the content displayed by the associated object to the top.

Scroll Down

Scrolls the content displayed by the associated object to the bottom.

Scroll Page Left

Scrolls the content displayed by the associated object to the left by one
page.

Scroll Page Right

Scrolls the content displayed by the associated object to the right by one
page.

Scroll Page Up

Scrolls the content displayed by the associated object to the top by one
page.

Scroll Page Down

Scrolls the content displayed by the associated object to the bottom by one
page.
