PM Designer Operation Manual
4-55
CHAPTER 4 DESIGNING SCREENS
Property Description
Timeout Check this option so the data entry will be cancelled if the numeric keypad does not
receive any input within the specified time. Timeout
Timeout
Time
Specifies the maximum time that the numeric keypad will wait to get a new input. If
there is no input within the specified time, the numeric keypad will be closed and the
data entry will be cancelled.
Notification Check this option so the numeric entry will notify the specified bit after it finishes
outputting the entered value to the destination variable.
Signal Select one of the following signal for the notification:
Signal Description
Level Set the specified bit to the specified state.
Pulse Send a positive pulse to the specified bit.
Bit Specifies the bit that receives the notification.
Notification
State Specifies the state (On or Off) that is used for the notification.
Operator
Confirmation
Check this option if you want the operator to confirm what he/she enters for the
numeric entry. The Confirmation box will be displayed when a value is entered for
the numeric entry. If the operator selects “Yes” in the Confirmation box, the numeric
entry will write the entered value to the specified variable. If the operator selects
“No” or the operator does not respond within the specified time period (Maximum
Waiting Time), the numeric entry will cancel the data entry operation. Operator
Confirmation
Maximum
Waiting Time Specifies the maximum time that the numeric entry will wait for the operator’s
confirmation. The data entry will be cancelled if the operator does not respond
within this time.
Operation
Logging Check this option so the following three items will be recorded in the operation log
when the numeric entry outputs the entered value.
There are three recorded items:
1) The time when the operation is performed
2) The entered value
3) The predefined operation message
Message Enter the operation message of the first language here.
Operation
Logging
Click this button to bring up the Operation Message dialog box that you can edit the
operation message for all the languages.
Minimum Hold Time Available when the object is a button or switch. The touch operation of the button
will not be activated until the button is pressed and held down for the specified time
period (Minimum Hold Time).
