PM Designer Operation Manual
3-31
CHAPTER 3 CREATING PANEL APPLICATIONS
The following table describes how to read or use each of the items in the dialog box.
Item Description
Sounds Lists the sounds for the panel application. You can select a sound as the current selection. You can
also make multiple selections. To select a sound, click the row on its header column of that sound in
the list. To select multiple rows, click the row on its header column and use Ctrl + Click to add a row
to the selection.
The following table describes each column in the sound list.
Column Description
Number The number of the sound in the sound list. The number is an unsigned integer
starting from 0. It must be unique in the panel application. You can click the cell
and then edit the number.
Name The name of the sound. You can click the cell to select a sound predefined in
the Sound Database from the drop down list. To know how to predefine sounds
in Sound Database, please see
Section 2.1.3.
Type Displays the type of the sound.
OK Closes the dialog box and accepts all changes to the sound table.
Cancel Closes the dialog box and discards all changes to the sound table.
Import… Imports a sound from a sound file. The types of importable sound files include: WAV only.
Add Adds a sound from the Sound Database to the end of the sound table. To know how to use Sound
Database, please see
Section 2.1.3.
Insert Inserts a sound from the Sound Database before the selection. To know how to use Sound
Database, please see
Section 2.1.3. This button is available when the selection is made.
Delete Deletes all the selections. This button is available when the selection is made.
Move Up Moves the selection one item down in the list. This button is available when the selection is made.
Move Down Moves the selection one item up in the list. This button is available when the selection is made.
