11
PM Designer Operation Manual
11-18
Property Description
Sort Type Specifies how the alarm display sorts its list initially. This field is available when
the Type is not Alarm Marquee.
Note: When you want an alarm display to sort its list by the contents of a
column at runtime, simply touch the title of that column and the alarm display
will sort its list right away.
Language Select a language so you can view and edit the language dependent settings
in the Text group for that language. The language dependent properties in the
Text group include Font and Alarm Status Abbreviation.
Font Select a font for the text.
Check this option if you want the alarm display to have the Date column. This
field is available when the Type is Alarm History. Date
Select a format for displaying the date
Check this option if you want the alarm display to have the Time column. This
field is available when the Type is Alarm History. Time
Select a format for displaying the time
Alarm Block ID Check this option if you want the alarm display to have the Alarm Block ID
column.
Alarm Level Check this option if you want the alarm display to have the Alarm Level column.
Alarm ID Check this option if you want the alarm display to have the Alarm ID column.
Alarm Message Check this option if you want the alarm display to have the Alarm Message
column.
Cleared Alarms Check this option so the alarm display will show the records of cleared alarms.
This field is available when the Type is Alarm History.
Alarm ACK Check this option so the alarm display will show the records of acknowledged
alarms. This field is available when the Type is Alarm History.
Active Enter up to 3 characters that will be shown in the Alarm Status column for the
alarm records that record when an alarm occurs. This field is available when
the Type is Alarm History.
Cleared Enter up to 3 characters that will be shown in the Alarm Status column for the
alarm records that record when an alarm is cleared. This field is available
when the Type is Alarm History.
Alarm Status
Abbreviation
ACK Enter up to 3 characters that will be shown in the Alarm Status column for the
alarm records that record when an alarm is acknowledged. This field is
available when the Type is Alarm History.
Line Spacing Specifies the extra space in pixels for two adjacent rows of the alarm display.
This field is available when the Type is not Alarm Marquee.
Text
Item Spacing Specifies the extra space for every column of the alarm display. This field is
available when the Type is not Alarm Marquee.
Click the button to replace the selections of the L1 to L8 fields by the default
alarm message colors defined in the Alarm Properties dialog box. . This button
is available when the Type is not Alarm History.
L1,L2 … L8 Select a color for alarm level 1,2…8. The alarm display will show an alarm
message with this color if that alarm is defined as a level 1,2…8 alarm. This
field is available when the Type is not Alarm History.
Active Select a color for displaying the alarm records that record when an alarm
occurs. This field is available when the Type is Alarm History.
Cleared Select a color for displaying the alarm records that record when an alarm is
cleared. This field is available when the Type is Alarm History.
Alarm
Message
Color
ACK Select a color for displaying the alarm records that record when an alarm is
acknowledged. This field is available when the Type is Alarm History.
CHAPTER 11 ALARMS AND ALARM DISPLAYS
