PM Designer Operation Manual
5-5
CHAPTER 5 BUTTONS AND SWITCHES
Property Description
Operation Select the operation for the bit button. There are 7 choices: Set ON, Set OFF, Set ON Pulse,
Set OFF Pulse, Momentary ON, Momentary OFF, and Invert.
For details, see
Section 5.1.1 Basic Operations
Address
Type Specifies the type of variable in the Write Address field. The bit buttons support the following
three variable types:
Variable Type Description
Bit The variable is a bit variable.
Word The variable is a word variable. You need to specify which bit of
the word variable that is to be operated. Specify the bit number
(0~15) in the Bit Number field.
Double-word The variable is a double-word variable. You need to specify which
bit of the double-word variable that is to be operated. Specify the
bit number (0~31) in the Bit Number field.
Write
Address Specifies the bit variable to be operated when the Address Type is Bit.
Specifies the word variable that contains the bit to be operated when the Address Type is
Word.
Specifies the double-word variable that contains the bit to be operated when the Address Type
is Double-word.
Click this icon to bring up the Address Input Keypad and specify the desired address for the
Write Address field.
Click this icon to bring up the Select Tag dialog box and select the desired tag for the Write
Address field.
Write
Address
Bit
Number Specifies which bit of the variable specified in Write Address field is to be operated.
Minimum Pulse
Width The minimum width of the pulse that the Momentary ON and Momentary OFF operations must
generate. There are six choices available: 0.05, 0.1, 0.2, 0.3, 0.4, and 0.5 second.
Pulse Width The width of the pulse generated by the Set ON Pulse and Set OFF Pulse operations. There
are six choices available: 0.05, 0.1, 0.2, 0.3, 0.4, and 0.5 second.
Monitor Check this option if you want the bit button to monitor a specified bit and display its state.
Monitor Address
identical to Write
Address Specifies that the Monitor Address is identical to the Write Address. With this item checked,
you don’t need to specify the Monitor Address again. This item is available when the option
Monitor is checked.
Monitor
Address Specifies the bit variable to be monitored when the Address Type is Bit.
Specifies the word variable that contains the bit to be monitored when the Address Type is
Word.
Specifies the double-word variable that contains the bit to be monitored when the Address
Type is Double-word.
Click this icon to bring up the Address Input Keypad and specify the desired address for the
Monitor Address field.
Monitor
Address
Click this icon to bring up the Select Tag dialog box and select the desired tag for the Monitor
Address field.
ON Macro Check this option if you want the button to have an ON macro. Specify and edit the ON macro
in the ON Macro page. This option is available when the bit button operation is Set ON, Set ON
Pulse, Momentary ON, or Momentary OFF.
OFF Macro Check this option if you want the button to have an OFF macro. Specify and edit the OFF
macro in the OFF Macro page. This option is available when the bit button operation is Set
OFF, Set OFF Pulse, Momentary ON, or Momentary OFF.
Key The hard key that is used to operate the bit button. This item is available only when the target
panel has hard keys.
