PM Designer Operation Manual
3-45
CHAPTER 3 CREATING PANEL APPLICATIONS
3.6.7. Using General Commands
This section describes how to use the general commands provided by the type A command block. To issue a general
command, specify necessary parameters in the parameter registers and then turn on command flag #15 in Command Flag
Register.
You can request the panel to perform the following file operations using the general command and the default filename:
Operation
Parameter One Register
(Operation code)
Parameter Two
Register (Data ID)
Default Filename Format
Save logged data to
TXT file 1 ID of the data logger
(0~15) DL__.txt
Save logged alarms to
TXT file 2 (Not required) AL__.txt
Save alarm counts to
TXT file 3 (Not required) AC__.txt
Save recipe data to
TXT file 4 ID of the recipe block
(0~15) RB.txt
Save recipe data to
DAT file 5 ID of the recipe block
(0~15) RB.dat
Print screen to BMP
file (256 colors) 6 Number of the screen S__.bmp
Print screen to BMP
file (64K colors) 7 Number of the screen S__.bmp
Save logged
operations to TXT file 9 (Not required) OL__.txt
Save logged data to
LDF file 10 ID of the data logger
(0~15) DL__.ldf
Take picture and save
it to BMP file 12 ID of the USB camera
(0~3) CAM__.bmp
Take picture and save
it to JPG file 13 ID of the USB camera
(0~3) CAM__.jpg
Note for default filename format:
: ID of the data logger, ID of the recipe block, ID of the USB camera, or number of the screen
: date when saving the data; format is YYMMDD
: time when saving the data; format is hhmmss
