4
PM Designer Operation Manual
4-24
CHAPTER 4 DESIGNING SCREENS
Property Description
Transparent
Check this item to make parts of the picture transparent. The transparent parts are
pixels whose colors are identical to the specified transparent color. This item is
available when the picture is not a black and white picture.
Transparent Color
The transparent color. This item is available when the picture is not a black and white
picture.
FG Color
The color to paint the black part of a black and white picture. This item is available
when the picture is a black and white picture.
BG Color
The color to paint the white part of a black and white picture. This item is available
when the picture is a black and white picture.
Flip/Rotate Specifies the method to flip or rotate the picture before drawing it. There are 8 options:
Method Description
0° Do nothing
90° Rotates the picture clockwise by 90 degree
180° Rotates the picture clockwise by 180 degree
270° Rotates the picture clockwise by 270 degree
X Flips the picture over X axis
90° & X Rotates the picture clockwise by 90 degree and flips it over X Axis
Y Flips the picture over Y axis
90° & Y Rotates the picture clockwise by 90 degree and flips it over Y Axis
Tone Check this item to tone the picture.
Toning Color The color to tone the picture.
Left The X coordinate of the upper-left corner of the object.
Top The Y coordinate of the upper-left corner of the object.
Width The width of the object.
Height The height of the object.
Profile
Redraw Click this button to redraw the object on the screen with the current settings.
