PM Designer Operation Manual
10-17
CHAPTER 10 RECIPES AND RECIPE OBJECTS
10.7.5. Data Item Settings
This section describes how to define the display format for the values of each data item. The following is an example of the
Data Item page.
The following table describes each property in the Data Item page.
Property Description
Language Select a language so you can view and edit the settings for that language.
Name The name of data item #n. The data item names are defined in the Data Item page of the
Data Logger dialog box.
Display Check this option if you want the object to display data item #n.
Color Select a color for displaying data item #n.
Alignment The alignment for displaying data item #n. There are three types of alignment: Left, Center,
and Right.
Row #n
of the
property
table
Justification The justification for displaying data item #n. There are three types of justification:
Option Description
Zero Suppress The leading digits will not display when they are 0.
Leading Zeros All digits will display.
Leading Spaces The leading digits will display as blank character when they are 0.
Move Up Click the button to move the selected data item before the previous data item. The Move Up
button will help you to reorder the display sequence of the data items It will not be available
when multiple rows are selected or no row is selected.
Move Down Click the button to move the selected data item after the next data item. The Move Down
button will help you to reorder the display sequence of the data items It will not be available
when multiple rows are selected or no row is selected.
