4
PM Designer Operation Manual
4-14
CHAPTER 4 DESIGNING SCREENS
Property Description
Outlined Check this option if you want the ellipse to be outlined. Outline
Color Specifies the outline color for the selected state.
Solid Check this option if you want the ellipse to be solid. A solid ellipse is filled
with the specified pattern and colors.
Pattern Specifies the fill pattern for the selected state.
FG Color Specifies the color for the selected state that will be used for painting the
black part of the fill pattern.
Solid
BG Color Specifies the color for the selected state that will be used for painting the
white part of the fill pattern.
Left The X coordinate of the upper-left corner of the bounding rectangle of the
ellipse.
Top The Y coordinate of the upper-left corner of the bounding rectangle of the
ellipse.
Width The width of the bounding rectangle of the ellipse.
Profile
Height The height of the bounding rectangle of the ellipse.
Visibility
Controlled By Bit Check this option if the ellipse will be shown or hidden by the specified bit.
Control Bit Specifies the bit that shows or hides the ellipse.
Click to enter the bit address. Click to enter the bit tag.
Visibility
Control
Visible State Specifies the state (On or Off) that makes the ellipse visible.
6. You can click the following icons in the Draw toolbar to modify the properties of the ellipse.
Click Icon To
Select a color for the outline.
Select a color for painting the white part of the fill pattern.
Select a pattern for the fill pattern.
Select a color for painting the black part of the fill pattern.
