PM Designer Operation Manual
12-17
CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
Show Ticks Check this option if you want the X axis to have ticks.
Show Y-axis Grid Select this option if you want the X axis to have vertical grids.
Grid Color Select a color for the vertical grids.
Show Time Check this option if you want to display time. You need to select a format for
displaying the time.
Time Format The format of how the time is displayed. There are two kinds of format available.
Format Description
HH:MM HH: 00~23 (hour); MM: 00~59 (minute)
HH:MM:SS HH: 00~23 (hour); MM: 00~59 (minute); SS: 00~59
(second)
Show Date Check this option if you want to display date on the left top of the historic trend
graph object. You need to select a format for displaying the date.
Date Format The format of how the date is displayed. There are 12 kinds of format available:
dd/mm/yy, mm/dd/yy, yy/mm/dd, dd.mm.yy, mm.dd.yy, yy.mm.dd, dd-mm-yy,
mm-dd-yy, yy-mm-dd, dd-MMM-yy, MMM-dd-yy, and yy-MMM-dd.
Note: dd: 01~31 (day); mm: 01~12 (month); yy: 00~99 (year); MMM: JAN~DEC
(month)
Time/Date Font The font of the time/date.
Time/Date/Tick Color Select a color for the X axis and its ticks.
Number of Major
Divisions The number of major divisions for the Y axis. The minimum you can specify is
one.
Number of Sub-divisions The number of divisions between two adjacent major ticks. The minimum you can
specify is one.
Show Ticks Check this option if you want the Y axis to have ticks.
Show X-axis Grid Select this option if you want the Y axis to have horizontal grids.
Y
Axis
Grid Color Select a color for the horizontal grids.
Show Marks Check this option if you want the major ticks to have marks.
Font The font of the marks.
Dynamic Range Check this option if you want the minimum and maximum of the marks to be
controlled by the dynamic range parameter block of the associated object at
runtime.
Minimum The minimum of the marks. You can specify a 32-bit signed integer.
Maximum The maximum of the marks. You can specify a 32-bit signed integer.
Total Digits The total digits to be displayed for the marks.
Fractional Digits The number of fractional digits for the marks. For example, when the Maximum is
5000, the Total Digits is 4, and the Fractional Digits is 2, the mark for the
Maximum will be 50.00.
Position Select a position to locate the scale. The scale can be displayed on the left or on
the right or on the both side.
Mark
Mark/Tick Color Select a color for the marks and ticks.
