1
PM Designer Operation Manual
1-32
CHAPTER 1 INTRODUCTION
■
Data Loggers Node ( )
The Data Loggers node can have many Data Logger sub-nodes. Each Data Logger sub-node is associated with a data
logger of the panel application. You can do the following with the Data Loggers node:
1) Double-click it to expand or collapse the list of its sub-nodes.
2) Right-click it to get a popup menu with the following menu item:
Menu Item Description
Add Data Logger Create a new data logger.
■
Data Logger Node ( )
A Data Logger node is associated with a data logger of the panel application. You can do the following with the Data
Logger node:
1) Double-click it to open the Data Logger dialog box of the associated recipe block.
2) Right-click it to get a popup menu with the following menu item:
Menu Item Description
Delete Delete the associated data logger.
Properties Open the Data Logger dialog box of the associated data logger.
■
Operation Logging Node ( )
You can do the following with the Operation Logging node:
1) Double-click it to open the Operation Logging dialog box.
2) Right-click it to get a popup menu with the following menu item:
Menu Item Description
Properties... Open the Operation Logging dialog box.
■
Macros Node ( )
The Macros node can have many Macro sub-node. Each Macro node is associated with a macro of the panel application.
You can do the following with the Macros node:
1) Double-click it to expand or collapse the list of its sub-nodes.
2) Right-click it to get a popup menu with the following menu items.
Menu Item Description
Add Macro... Create a new macro.
Import Macro... Import a macro from an MCR file.
■
Macro Node ( )
Each Macro node is associated with a macro of the panel application. You can do the following with the Macro node:
1) Double-click it to open the editing window of the associated macro.
2) Right-click it to get a popup menu with the following menu items.
Menu Item Description
Open Open the editing window of the associated macro.
Close Close the editing window of the associated macro.
Rename Rename the associated macro.
Delete Delete the associated macro.
Export Macro... Export the associated macro to an MCR file.
