PM Designer Operation Manual
4-7
CHAPTER 4 DESIGNING SCREENS
Property Description
Left The X coordinate of the upper-left corner of the bounding rectangle of the
polyline.
Top The Y coordinate of the upper-left corner of the bounding rectangle of the
polyline.
Width The width of the bounding rectangle of the polyline.
Profile
Height The height of the bounding rectangle of the polyline.
Visibility Controlled
By Bit Check this option if the polyline will be shown or hidden by the specified bit.
Control Bit Specifies the bit that shows or hides the polyline.
Click to enter the bit address. Click to enter the bit tag.
Visibility
Control
Visible State Specifies the state (On or Off) that makes the line visible.
9. You can click the following icons in the Draw toolbar to modify the properties of the polyline.
Click Icon To
Select a style for the polyline.
Select a color for the polyline.
