PM Designer Operation Manual
8-11
Property Description
Graphical shape settings For details about the following properties, Section 4.3.1.4 Setting up the Shape of an
Object. , Border Color, BG Color
Swing Specifies the types of swing. For details, see ?, ?.
Direction Specifies the direction that the needle moves. Now only the Clockwise is available.
Data Type The data type of the monitored variable. The supported data types include: 16-Bit
Unsigned Integer, 32-Bit Unsigned Integer, 16-Bit Signed Integer, 32-Bit Signed Integer,
16-Bit BCD, 32-Bit BCD, 32-Bit Floating Point, 16-Bit Signed BCD (LMB), 32-Bit Signed
BCD (LMB), 16-Bit Signed BCD (LMD), and 32-Bit Signed BCD (LMD).
Monitor Address Specifies the variable to be monitored.
Click to enter an address for this field. Click to select a tag for this field.
Dynamic
Range Check this option so the minimum and the maximum of the monitored variable will be
specified at runtime. When this option is selected, the minimum and maximum of the
marks for the scale of the meter can be specified at runtime too. The data that specifies
the above two ranges should be set and arranged correctly in a memory block called the
dynamic range parameter block. You need to specify the dynamic range parameter block
for the meter in the Dynamic Range Parameter Block field. Dynamic
Range
Dynamic
Range
Parameter
Block Specifies the variable that stores the dynamic range parameter block for the meter when
the Dynamic Range is selected. Click to enter an address for this field. Click to
select a tag for this field.The following table shows the content of the parameter block
when the data type is 16-bit and the scale of the meter is not dynamic.
Word Parameter
0 The minimum of the monitored variable
1 The maximum of the monitored variable
The following table shows the content of the parameter block when the data type is 16-bit
and the scale of the meter is dynamic.
Word Parameter
0 The minimum of the monitored variable
1 The maximum of the monitored variable
2, 3 The minimum of the mark for the scale; 32-bit integer number
4, 5 The maximum of the mark for the scale; 32-bit integer number
The following table shows the content of the parameter block when the data type is 32-bit
and the scale of the meter is not dynamic.
Word Parameter
0, 1 The minimum of the monitored variable
2, 3 The maximum of the monitored variable
The following table shows the content of the parameter block when the data type is 32-bit
and the scale of the meter is dynamic.
Word Parameter
0, 1 The minimum of the monitored variable
2, 3 The maximum of the monitored variable
4, 5 The minimum of the mark for the scale; 32-bit integer number
6, 7 The maximum of the mark for the scale; 32-bit integer number
Continued
CHAPTER 8 GRAPHS AND CHARTS
