7
PM Designer Operation Manual
7-10 CHAPTER 7 DISPLAYING AND INPUTTING DATA
Property Description
Display Type The display type for the value of the monitored variable. The following table shows the available
display types for each data type.
Data Type Available Display Types
16-Bit Unsigned Integer 16-Bit Unsigned Decimal, 16-Bit Hexadecimal, 16-Bit Octal
32-Bit Unsigned Integer 32-Bit Unsigned Decimal, 32-Bit Hexadecimal, 32-Bit Octal
16-Bit Signed Integer 16-Bit Signed Decimal
32-Bit Signed Integer 32-Bit Signed Decimal
16-Bit BCD 16-Bit Unsigned Decimal
32-Bit BCD 32-Bit Unsigned Decimal
32-Bit Floating Point 32-Bit Floating Point
16-Bit Signed BCD (LMB) 16-Bit Signed Decimal
32-Bit Signed BCD (LMB) 32-Bit Signed Decimal
16-Bit Signed BCD (LMD) 16-Bit Signed Decimal
32-Bit Signed BCD (LMD) 32-Bit Signed Decimal
Monitor Address Specifies the monitored variable.
Click to enter an address for this field. Click to select a tag for this field.
Font The font of the displayed value.
Text Color The color of the displayed value.
Total Digits The number of digits to be displayed.
Fractional Digits When the Display Type is 32-bit Floating Point, this property specifies the number of fractional
digits to be displayed.
When the Display Type is not 32-bit Floating Point, this property specifies not only the number of
fractional digits to be displayed but also the number of least significant digits to be displayed as
the fractional part. With this feature, an integer can be shown as a fixed point number.
Example:
Display Type
Total
Digits
Fractional
Digits
Justification
Monitored
Value
Displayed
Value
32-bit Floating Point 4 2 Zero Suppress 12.34 12.34
32-bit Floating Point 4 2 Zero Suppress 123.4 23.40
16-bit Signed
Decimal 5 2 Zero Suppress 12345 123.45
16-bit Signed
Decimal 5 2 Zero Suppress -5 -0.05
Alignment The alignment of the displayed value. There are three types of alignment: Left, Center, and
Right.
Justification The justification of the displayed value. There are three types of justification:
Option Description
Zero Suppress The leading digits will not display when they are 0.
Leading Zeros All digits will display.
Leading Spaces The leading digits will display as blank character when they are 0.
