PM Designer Operation Manual
4-43
CHAPTER 4 DESIGNING SCREENS
■ Text Sub-page, OFF Text Sub-page, and ON Text Sub-page
You can use the Text sub-page, OFF Text sub-page, and ON Text sub-page to set up the text of the inner label for the
corresponding state and the current language. The language you are setting for is specified by the Language item in the
Label page.
The following are examples of the Text pages:
Text sub-page ON Text sub-page
The following table describes each property in the Text sub-page, OFF Text sub-page, and ON Text sub-page.
Property Description
Copy from Note Click this button to replace the current text by the text of Note in the General page.
Copy to ON State Click this button to use the current text to replace the text of ON state.
Copy to OFF
State Click this button to use the current text to replace the text of OFF state.
Font The font of the text. You can use the drop-down list to select a font.
Click to bring up the Font Templates dialog box and select a font for the text. You can
change the font templates before selecting a font in that dialog box.
Color The color of the text. To specify the color, click the corresponding Color icon and select a color
from the Color palette.
Blink Check this item so the text will blink.
Transparent Check this item to make the background of the characters transparent.
BG Color The background color of the text.
Line Spacing The distance (in pixels) between two adjacent lines of the text.
Character
Spacing The distance (in pixels) between two adjacent characters of the text.
Continued
