12
PM Designer Operation Manual
12-26
CHAPTER 12 DATA COLLECTION AND HISTORIC DISPLAYS
Property Description
Show Data Point Markers Check this option so the line chart will put a square mark on every data point.
Show Connected Lines Check this option so the single record line chart will display a line connecting all the data
points in sequence.
Date Check this option if you want the object to display the Date column. You need to select a
format for displaying the date.
Time Check this option if you want the object to display the Time column. You need to select a
format for displaying the time.
Color Select a color for the text.
Time/Date
Display
Font Select a font for the title text.
Box> Check this option so the single record line chart will display a cursor. You can touch and
drag the cursor to the data point(s) that you want to select.
Cursor
Color Select a color for the cursor.
Value
Display
Font Select a font for displaying the values of the selected data point(s).
Show
Cursor
Cursor
Data
Receiving
Buffer The variable whose data is to be read and displayed the cursor data.
Click to enter an address for this field. Click to select a tag for this field.
Box> Check this option so the single record line chart will display a reference line.
Reference
Line Data
Block The variable whose data is to be read and displayed the reference data.
Click to enter the word address. Click to enter the word tag.
Show/Hide
Controlled
By Bit Check this option if you want to show or hide the reference line controlled by the specified
bit.
Reference
Line
Show/Hide
Control Bit Specifies the bit that controls the reference line show/hide.
Click to enter the bit address. Click to enter the bit tag.
