5
PM Designer Operation Manual
5-24
CHAPTER 5 BUTTONS AND SWITCHES
Property Description
Dynamic Range Check this option so the minimum and the maximum of the variable will be specified at
runtime. When this option is selected, the minimum and maximum of the marks for the
scale of the slide switch can be specified at runtime too. The data that specifies the
above two ranges should be set and arranged correctly in a memory block called the
dynamic range parameter block. You need to specify the dynamic range parameter
block for the slide switch in the Dynamic Range Parameter Block field. Dynamic
Range
Dynamic Range
Parameter
Block Specifies the variable that stores the dynamic range parameter block for the slide
switch when the Dynamic Range is selected. Click to enter an address for this
field. Click to select a tag for this field.
The following table shows the data arrangement of the parameter block when the data
type is 16-bit and the scale of the slide switch is not dynamic.
Word Parameter
0 The minimum of the variable
1 The maximum of the variable
The following table shows the data arrangement of the parameter block when the data
type is 16-bit and the scale of the slide switch is dynamic.
Word Parameter
0 The minimum of the variable
1 The maximum of the variable
2, 3 The minimum of the mark for the scale; 32-bit integer number
4, 5 The maximum of the mark for the scale; 32-bit integer number
The following table shows the data arrangement of the parameter block when the data
type is 32-bit and the scale of the slide switch is not dynamic.
Word Parameter
0, 1 The minimum of the variable
2, 3 The maximum of the variable
The following table shows the data arrangement of the parameter block when the data
type is 32-bit and the scale of the slide switch is dynamic.
Word Parameter
0, 1 The minimum of the variable
2, 3 The maximum of the variable
4, 5 The minimum of the mark for the scale; 32-bit integer number
6, 7 The maximum of the mark for the scale; 32-bit integer number
Minimum The minimum of the variable to be controlled.
Maximum The maximum of the variable to be controlled.
Border Color The border color of the knob. To specify the color, click the corresponding Color icon
and select a color from the Color palette. Knob
BG Color The color inside the border. To specify the color, click the corresponding Color icon
and select a color from the Color palette.
