3
PM Designer Operation Manual
3-34
CHAPTER 3 CREATING PANEL APPLICATIONS
10) Asking the associated scatter charts to read and draw a new set of data.
11) Asking the associated scatter charts to clear its content.
Enabling Word (Enabling Bits #0 ~ #15)
You can use the enabling bits to enable the following operations:
1) The data collection of data loggers
Parameter One Register
This word specifies the parameter #1 for the specified operation.
Parameter Two Register
This word specifies the parameter #2 for the specified operation.
Parameter Three Register
This word specifies the parameter #3 for the specified operation.
Parameter Four Register
This word specifies the parameter #4 for the specified operation.
■ Type A Status Words
You can have the following status words for the application.
Status Word Description
Command Status Word
(Command Flag Ack. Bits #0 ~ -#15)
Stores the acknowledge bits of the command bits #0 ~ #15.
Low Trigger Ack. Word
(Trigger Ack. Bits #0 ~ #15)
Stores the acknowledge bits of the trigger bits #0 ~ #15.
High Trigger Ack. Word
(Trigger Ack. Bits #16 ~ #31)
Stores the acknowledge bits of the trigger bits #16 ~ #31.
Current Screen Number Word Stores the current main screen number.
Current Recipe Block ID Word Stores the current recipe block number.
Current Recipe Number Word Stores the current recipe number of the current recipe block.
Current User Level Word Stores the current user level.
Current Language Word Stores the current language number.
