CHAPTER 4 DESIGNING SCREENS
Property Description
Color Controlled
By Bit Check this option if the color of the rectangle will be controlled by the
specified bit.
Control Bit
Specifies the bit that controls the color.
Click to enter the bit address. Click to enter the bit tag.
Color
Control
State Select the state that you want to view or define the colors for.
Border Check this option if you want the rectangle to have border.
Thickness Specifies the thickness of the border.
Color Specifies the border color for the selected state.
Border
Style Select a line style for the border.
Solid
Check this option if you want the rectangle to be solid. A solid rectangle is
filled with the specified pattern and colors. This field is available when the
Border is selected.
Pattern Specifies the fill pattern for the selected state.
FG Color
Specifies the color for the selected state that will be used for painting the
black part of the fill pattern.
Solid
BG Color
Specifies the color for the selected state that will be used for painting the
white part of the fill pattern.
Left The X coordinate of the upper-left corner of the rectangle.
Top The Y coordinate of the upper-left corner of the rectangle.
Width The width of the rectangle.
Profile
Height The height of the rectangle.
Visibility
Controlled By Bit
Check this option if the rectangle will be shown or hidden by the specified bit.
Control Bit
Specifies the bit that shows or hides the rectangle.
Click to enter the bit address. Click to enter the bit tag.
Visibility
Control
Visible State Specifies the state (On or Off) that makes the rectangle visible.
6. You can click the following icons in the Draw toolbar to modify the properties of the rectangle.
Click Icon To
Select a line style for the border.
Select a color for the border.
Select a color for painting the white part of the fill pattern.
Select a pattern for the fill pattern.
Select a color for painting the black part of the fill pattern.
