PROFINET communication
Parameterising the temperature measurement
Four (two) analog inputs for resistance tests − EPM−S404
12
l
652 EDSIO1000 EN 7.0
Range Signal range Measured value Measuring range Range Signal range Measured value
(Fct. no.)
4−wire: 0 ... 600 W
(E1
h
)
705.5 W 32511
dec
Overflow
0 ... 600 W 0 ... 27648
dec
Nominal range
− − Underflow
4−wire: 0 ... 3000 W
(E2
h
)
3528 W 32511
dec
Overflow
0 ... 3000 W 0 ... 27648
dec
Nominal range
− − Underflow
Diagnostics and alarm
Trigger Process alarm Diagnostic alarm Parameterisable
Configuration/parameterisation error − X −
Open circuit detected − X X
Measuring range exceeded − X −
Measuring range not reached − X −
Limit value exceeded X − X
Limit value not reached X − X
Process alarm lost − X −
Process alarm
A process alarm causes a call of the OB 40. Within the OB 40 you have the possibility of
determining the logic basic address of the module that has triggered the process alarm via
the local word 6. Further information on the triggering event can be found in the "Local
double word 8".
Local double word 8 of OB 40:
Local byte Bit 7 ... 0
8 Bit 0: Limit value exceeded channel 1
Bit 1: Limit value exceeded channel 2
Bit 2: Limit value exceeded channel 3
Bit 3: Limit value exceeded channel 4
Bit 7 ... 4: 0 (fixed)
9 Bit 0: Limit value not reached channel 1
Bit 1: Limit value not reached channel 2
Bit 2: Limit value not reached, channel 3
Bit 3: Limit value not reached, channel 4
Bit 7 ... 4: 0 (fixed)
10 ... 11 Ticker value at the time of the alarm
After mains connection, a timer (
ms ticker) is started which after 65535 ms starts with 0 again.
