About this documentation 1
l
13 EDSIO1000 EN 7.0
Module function Module designation Type
designation
From
hardware
version
From
software
version
 ‚ ƒ
Bus coupler module
CANopen CANopen EPM−S110 1D 30
PROFIBUS PROFIBUS−DP EPM−S120 1D 30
EtherCAT EtherCAT EPM−S130 1D 28
PROFINET PROFINET EPM−S140 1D 10
DeviceNet DeviceNet EPM−S150 1D 10
Modbus TCP Modbus TCP EPM−S160 1D 10
I/O compound module
Digital I/O
2 digital inputs DI 2, DC 24 V EPM−S200 1B −
4 digital inputs DI 4, DC 24 V EPM−S201 1B −
8 digital inputs DI 8, DC 24 V EPM−S202 1B −
4 digital inputs three−wire conductor DI 4, DC 24 V EPM−S203 1B −
2 digital inputs NPN DI 2, NPN, DC 24 V EPM−S204 1B −
4 digital inputs NPN DI 4, NPN, DC 24 V EPM−S205 1B −
8 digital inputs NPN DI 8, NPN, DC 24 V EPM−S206 1B −
2 digital inputs, time stamp DI 2, 2 ms, DC 24 V EPM−S207 1B 10
2 digital outputs 0.5 A DO 2, DC 24 V, 0.5 A EPM−S300 1B −
4 digital outputs 0.5 A DO 4, DC 24 V, 0.5 A EPM−S301 1B −
8 digital outputs 0.5 A DO 8, DC 24 V, 0.5 A EPM−S302 1B −
2 digital outputs 0.5 A NPN DO 2, NPN, DC 24 V, 0.5 A EPM−S303 1B −
4 digital outputs 0.5 A NPN DO 4, NPN, DC 24 V, 0.5 A EPM−S304 1B −
8 digital outputs 0.5 A NPN DO 8, NPN, DC 24 V, 0.5 A EPM−S305 1B −
2 digital outputs 2 A DO 2, DC 24 V, 2 A EPM−S306 1B −
4 digital outputs 2 A DO 4, DC 24 V, 2 A EPM−S309 1B −
2 digital outputs, time stamp DO 2, 1 ms, DC 24 V, 0.5 A EPM−S310 1B 10
2 relay outputs Relay 2, AC 230 V, 3 A EPM−S308 1B −
Analog I/O
2 analog inputs, 12 bits, 0 ... 10 V AI 2, 12 bits, DC 0...10 V EPM−S400 1B 10
4 analog inputs, 12 bits, 0 ... 10 V AI 4, 12 bits, DC 0...10 V EPM−S401 1B 10
2 analog inputs, 12 bits, 0/4 ... 20 mA AI 2, 12 bits, DC 0/4...20 mA EPM−S402 1B 10
4 analog inputs, 12 bits, 0/4 ... 20 mA AI 4, 12 bits, DC 0/4...20 mA EPM−S403 1B 10
2 analog inputs, 16 Bit, 0 ... 10 V AI 2, 16 Bit, DC 0...10 V EPM−S406 1B 10
2 analog inputs, 16 Bit, 0/4 ... 20 mA AI 2, 16 Bit, DC 0/4...20 mA EPM−S408 1B 10
2 analog outputs, 12 bits, 0 ... 10 V AO 2, 12 bits, DC 0...10 V EPM−S500 1B 10
4 analog outputs, 12 bits, 0 ... 10 V AO 4, 12 bits, DC 0...10 V EPM−S501 1B 10
2 analog outputs, 12 bits, 0/4 ... 20 mA AO 2, 12 bits, DC
0/4...20 mA
EPM−S502 1B 10
4 analog outputs, 12 bits, 0/4 ... 20 mA AO 4, 12 bits, DC
0/4...20 mA
EPM−S503 1B 10
Temperature measurement
4(2) analog inputs resistor AI 4, 16 bits, resistor EPM−S404 1B 10
2 analog inputs thermocouple AI 2, 16 bits, thermo EPM−S405 1B 10
