8.19.3 Status of the digital inputs
Via the index I6000
h
the status of the digital inputs can be displayed.
Index Name Possible settings Important
Lenze Selection
I6000
h
Digital input 0 {1} 255 Read only
Digital input status
^ 356
1 Byte 1
2 Byte 2
... ...
80 Byte 80
8.19.4 Status of the digital outputs
Via the index I6200
h
the status of the digital outputs can be displayed:
Index Name Possible settings Important
Lenze Selection
I6200
h
*
Digital output 0 {1} 255 l Digital output status
l The outputs can be set
manually (forcing):
– Depends on CAN status and
I2360
h
^ 356
1 Byte 1
2 Byte 2
... ...
80 Byte 80
8.19.5 Status of the analog inputs
Via the index I6401
h
the status of the analog inputs can be displayed.
Index Name Possible settings Important
Lenze Selection
I6401
h
Analog input −32768 {1} 32767 Display only
Analog input status
^ 356
1 Channel 1
2 Channel 2
... ...
36 Channel 36
8.19.6 Status of the analog outputs
Via the index I6411
h
the status of the analog outputs can be displayed:
Index Name Possible settings Important
Lenze Selection
I6411
h
*
Analog output −32768 {1} 32767 l Analog output status
l The outputs can be set
manually (forcing):
– Depends on CAN status and
I2360
h
^ 356
1 Channel 1
2 Channel 2
... ...
36 Channel 36
