PROFINET communication
Index table
12
l
625 EDSIO1000 EN 7.0
12.5 Index table
Within a module you can access the I/O data, parameter data and diagnostic data via index
numbers. Under PROFINET the index numbers are summarised in the following areas:
0000
h
... 7FFF
h
: Manufacturer−specific index numbers
8000
h
... F7FF
h
: Standard index numbers of PROFINET.
Information on this can be found in the PROFINET specification. There, the "index" is also
called "data record". In the following, all supported index numbers are listed.
Index Description
Readable index numbers
0000
h
Read DS 00
h
diagnostic data
0001
h
Read DS 01
h
diagnostic data
007D
h
Read all parameter data
007E
h
Read DS 00
h
of the parameter data
007F
h
(only I/O compound modules) Read DS 01
h
of the parameter data
0080
h
. 0090
h
(only I/O compound modules) Read DS 80
h
. DS 90
h
of the parameter data
8000
h
/ 8001
h
/ 800A
h
/ 800B
h
/ 800C
h
/
8010
h
/ 8011
h
/ 8012
h
/ 8013
h
/ 801E
h
/
802A
h
/ 802B
h
/ 802C
h
/ 802D
h
/ 802F
h
/
8030
h
/ 8031
h
/ 8050
h
/ 8051
h
/ 8052
h
/
8053
h
/ 8054
h
/ 8060
h
/ 8061
h
/ 8062
h
/
8070
h
/ 8080
h
/ 8090
h
See PROFINET specification
8028
h
(only I/O compound modules) Read input data of a sub−slot
8029
h
(only I/O compound modules) Read output data of a sub−slot
AFF0
h
Read I&M 0 (serial no., name, SW/HW version)
AFF1
h
(only PROFINET bus coupler9) Read I&M 1 (designation and mounting place)
AFF2
h
(only PROFINET bus coupler9) Read I&M 2 (date of installation)
AFF3
h
(only PROFINET bus coupler9) Read I&M 3 (comment)
C000
h
/ C001
h
/ C00A
h
/ C00B
h
/ C00C
h
/
C010
h
/ C011
h
/ C012
h
/ C013
h
/ E000
h
/
E001
h
/ E002
h
/ E00A
h
/ E00B
h
/ E00C
h
/
E010
h
/ E011
h
/ E012
h
/ E013
h
/ E030
h
/
E040
h
/ E050
h
/ F000
h
/ F001
h
/ F00A
h
/
F00B
h
/ F00C
h
/ F010
h
/ F011
h
/ F012
h
/
F013
h
/ F020
h
/ F80C
h
/ F820
h
/ F821
h
/
F830
h
/ F831
h
/ F840
h
/ 8041
h
/ F842
h
See PROFINET specification
Writable index numbers
007D
h
Write all parameter data
007E
h
Write DS 00
h
of the parameter data
007F
h
(only I/O compound modules) Write DS 01
h
of the parameter data
0080
h
. 0090
h
(only I/O compound modules) Write DS 80
h
. DS 90
h
of the parameter data
AFF1
h
(only PROFINET bus coupler9) Write I&M 1 (designation and mounting place)
AFF2
h
(only PROFINET bus coupler9) Write I&M 2 (date of installation)
AFF3
h
(only PROFINET bus coupler9) Write I&M 3 (comment)
