10.12.3 Standard objects
The following indexes can be used for diagnostic purposes. They show operating states.
Settings cannot be made.
Index Designation Possible settings IMPORTANT
Lenze Selection
0x1000
h
Device type Device type of the module
Read only
0x1003
h
Last error Current error, the fault memory
is cleared by a reset or power
cycle.
Read only
0 Last error
1 Error code
Bus status
2 Module
number
Module slot
3 Error
description
Error code
0x1008
h
Device name Device name of the module
Read only
0x1009
h
Hardware
Version Hardware version of the module
Read only
0x100A
h
Software
version Software version of the module
Read only
0x100B
h
System version Delivery status, depending on
FPGA versions of bus coupler and
modules, at least system version
2
Read only
0x1018
h
Identity General data of the EtherCAT bus
coupler module
Read only
0 Identity object
1 Vendor ID
2 Product code
3 Revision
number
4 Serial number
0x1600
h
...
0x163F
Output
mapping
modules
0 RxPDO Map Number of outputs at this slot
Entry only exists for slots with
parameterisable modules
1 Output
mapping
E.g.: 0x7000:01, 1 > the first
output on slot 0 is 1 bit long
2 Output
mapping
... ...
