CANopen communication
Transmitting process data
PDO mapping for counters and encoder evaluation
8
l
271 EDSIO1000 EN 7.0
EPM−S603 status word
Bit Designation Function
0 − Reserved
1 − Reserved
2 STS_SW−GATE Software gate status (set if SW gate active)
3 − Reserved
4 − Reserved
5 STS_GATE Status of internal gate (set if internal gate active)
6 − Reserved
7 STS_C_DN Status set for counter direction backwards
8 STS_C_UP Status set for counter direction forwards
9 − Reserved
10 − Reserved
11 STS_OFLW* Status set in the case of overflow
12 STS_UFLW* Status set in the case of underflow
13 STS_ZP* Status set in the case of zero crossing
14 − Reserved
15 − Reserved
* The bits are set until reset with RES_SET (bit 6 control word)
EPM−S603 control word
Bit Designation Function
0 − Reserved
1 − Reserved
2 SW_GATE_SET Sets the software gate
3 − Reserved
4 − Reserved
5 − Reserved
6 RES_SET Resets bits STS_CMP, STS_END, STS_OFLW, STS_UFLW and STS_ZP with a
rising edge
7 − Reserved
8 − Reserved
9 − Reserved
10 SW_GATE_RESET Resets the software gate
11 − Reserved
12
13
14
15
