Product description
I/O compound modules − counter
One counter 32 bits, 24 V DC − EPM−S600
3
l
159 EDSIO1000 EN 7.0
EPM−S600: rated data
Switching frequencies
for ohmic loads, max. 10 kHz
for inductive loads, max. 0.5 Hz
for lamp loads, max. 10 kHz
Limitation (internal) of the inductive
breaking voltage L+ (−52 V)
Short circuit protection
Type Electronically
Operating threshold 1 A
Output data size 10 bytes
Counter
Number of counters 1
Counter width 32 bits
Frequency
Input frequency, max 100 kHz
Counting frequency, max 400 kHz
Operating mode
Incremental encoder Possible
Pulse/direction Possible
Pulse Not possible
Frequency measurement Not possible
Period duration measurement Not possible
Connection
Gate connection Possible
Latch connection Possible
Reset connection Possible
Counter output Possible
Status, alarm, diagnostics
Status display Yes
Alarms Yes, parameterisable
Process alarm Yes, parameterisable
Diagnostic alarm Yes, parameterisable
Diagnostic function Yes, parameterisable
Diagnostic information can be read out Possible
Module status Green LED
Module error display Red LED
Channel error display None
Electrical isolation
Between the channels and the backplane
bus Yes
Insulation checked with DC 500 V
