Lenze I/O system 1000 System Manual - Manual (Page 599)

DeviceNet communication
Time stamp parameterising
2 digital inputs with time stamp function − EPM−S207
11
l
599 EDSIO1000 EN 7.0
11.7 Time stamp parameterising
11.7.1 2 digital inputs with time stamp function − EPM−S207
Parameter data
Pos. in
string of
digits Name Description/value Lenze
1 Length − process
image input data Length of input data (backplane bus communication); the values
are specified by the system. Other values are not permissible. 14
h
or 3C
h
(fix)
2 Length − process
image output data Length of output data (backplane bus communication); the
values are specified by the system. Other values are not
permissible. 00
h
(fix)
3 Input delay DI1 00
h
= 1 ms
02
h
= 3 ms
04
h
= 10 ms
07
h
= 86 ms
09
h
= 342 ms
0C
h
= 273 ms
Other values are not permissible.
02
h
4 Input delay DI2 02
h
5 Edge 0−1 an DI x Time stamp entry on rising edge
Bit 0: DI1 (0: inhibit, 1 = enable)
Bit 1: DI2 (0: inhibit, 1 = enable)
Bits 7 ... 2: Reserved 00
h
6 Edge 1−0 at DI x Time stamp entry on falling edge
Bit 0: DI1 (0: inhibit, 1 = enable)
Bit 1: DI2 (0: inhibit, 1 = enable)
Bits 7 ... 2: Reserved 00
h
11.7.2 2 digital outputs with time stamp function − EPM−S310
Parameter data
Pos. in
string of
digits Name Description/value Lenze
1 Length − process
image input data Length of input data (backplane bus communication); the values
are specified by the system. Other values are not permissible. 14
h
or 3C
h
(fix)
2 Length − process
image output data Length of output data (backplane bus communication); the
values are specified by the system. Other values are not
permissible. 00
h
(fix)
