Product description
Bus coupler modules
PROFINET − EPM−S140
3
l
50 EDSIO1000 EN 7.0
Status displays
Fieldbus status LEDs 0
View Pos. Designation Colour Explanation
1
10
1 PWR Green On: bus coupler is supplied with voltage
2 SF Red
On: System error; error at PROFINET or at
backplane bus
3 BS Green Bus error; error in PROFINET communication
4 MT Yellow Maintenance: PROFINET maintenance request
5 LINK1 Green Physical connection to PROFINET (P1)
6 ACT1 Green Communication via PROFINET (P1)
7 LINK2 Green Physical connection to PROFINET (P2)
8 ACT2 Green Communication via PROFINET (P2)
9
− − Not assigned
SLIO001 10
PWR SF BS MT LINK1 ACT1 LINK2 ACT2 Status
Green Red Green Yellow Green Green Green Green
On − − − − − − − The PROFINET bus coupler is supplied with
voltage.
On Off 0.5 Hz − [On] − [On] − It is not possible to establish a connection
with the PROFINET I/O controller. A
connection to the switch, however, exists
(no AR is active) LNK1 or LNK2 is on.
On Off On − Off Off Off Off There is no physical connection to the
Ethernet. LNK1 and LNK2 are off.
On − Off − [On] Pulse [On] Pulse A connection to a PROFINET I/O controller
has been established (at least one AR is
active) LNK1 or LNK2 is on.
On On − − − − − − l A diagnostic message not yet
acknowledged is available.
l Error at the backplane bus (e.g. module
defective, bus disturbed).
l Error at firmware update (only visible
for a short time, afterwards restart).
On 2 Hz On − On − On − IP address error
l No valid IP address has been assigned.
l The assigned IP address already exists
in the system.
On − 1 Hz 1 Hz − − − − A firmware update is currently being
executed. Here, BS and MT are blinking
alternately.
On − − − 2 Hz − 2 Hz − Identification via DCP. Depending on the
connection, LINK1 or LINK2 is blinking for
3 seconds with 2 Hz.
On On − On − − − − Maintenance request (Maintenance
demanded/requested)
l After the coupler has been
parameterised, no sync frame has been
received.
l Jitter is outside the limits (renewed
synchronisation).
l Switch has rejected 10 frames
(network overloaded).
l Error at the system SLIO bus (version
error).
"−": Not relevant; "x Hz": Blinking with x Hz; "[an]": Option; "Puls": Pulsating
