Lenze I/O system 1000 System Manual - Manual (Page 540)

EtherCAT Kommunikation
Diagnostics
Access to diagnostic data
10
l
540 EDSIO1000 EN 7.0
EPM−S600 − diagnostic alarm
Diagnostic byte Bit 7 ... 0
1 Bit 0: Set if module fault
Bit 1: 0 (fixed)
Bit 2: Set in the case of an external error
Bit 3: Set in the case of a channel error
Bit 6 ... 4: 0 (fixed)
Bit 7: Parameterisation error
2 Bit 3 ... 0: Module class, 1000
b
: function module
Bit 4: Channel information available
Bit 7 ... 5: 0 (fixed)
3 0 (fixed)
4 Bit 5 ... 0: 0 (fixed)
Bit 6: Process alarm lost
Bit 7: 0 (fixed)
EPM−S601 − diagnostic alarm
Diagnostic byte Bit 7 ... 0
1 Bit 0: Set if module fault
Bit 1: 0 (fixed)
Bit 2: Set in the case of an external error
Bit 3: Set in the case of a channel error
Bit 6 ... 4: 0 (fixed)
Bit 7: Parameterisation error
2 Bit 3 ... 0: Module class, 1000
b
: function module
Bit 4: Channel information available
Bit 7 ... 5: 0 (fixed)
3 0 (fixed)
4 Bit 5 ... 0: 0 (fixed)
Bit 6: Process alarm lost
Bit 7: 0 (fixed)
EPM−S602 diagnostic alarm
Diagnostic byte Bits 7 ... 0
1 Bit 0: set if module fault
Bit 1: set if internal error
Bit 2: set if external error
Bit 3: set if channel error exists
Bit 4: set if there is no external voltage supply
Bits 7 .... 5: 0 (fixed)
2 Bits 3 ... 0: module class, 1000
b
: function module
Bit 4: set if channel information available
Bits 7 ... 5: 0 (fixed)
3 0 (fixed)
4 Bits 5 ... 0: 0 (fixed)
Bit 6: set if process alarm lost
Bit 7: 0 (fixed)
EPM−S603 − diagnostic alarm
Diagnostic byte Bit 7 ... 0
1 0 (fixed)
2 Bit 3 ... 0: Module class, 1000
b
: function module
Bit 4: Channel information available
Bit 7 ... 5: 0 (fixed)
3 0 (fixed)
4 0 (fixed)
