Product description
I/O compound modules − counter
Two counters 32 bits, 24 V DC − EPM−S603
3
l
208 EDSIO1000 EN 7.0
Parameterisable functions
Counting functions Description
Counting
continuously The counter counts from 0 to the counting limit, then skips to the opposite counting limit
and continues to count from there.
Signal evaluation Description
Single rotary
transducer
Connection to input "A/pulse" and "B/direction"
Double rotary
transducer
Quadruple rotary
transducer
Direction Pulse at input "A/pulse" and direction at "B/direction"
Additional functions Description
Gate function The gate function serves to start, stop, and interrupt a counting function. In the case of
this counter the internal gate (I−gate) is conform to the software gate (SW gate) which
you control via your user program (status word in the output area).
