Product description
Bus coupler modules
DeviceNet − EPM−S150
3
l
56 EDSIO1000 EN 7.0
SF RD BA State
Red Green Yellow
On Off Off Invalid switch position at the address switch
Off On Off Baud rate has been accepted successfully
1 Hz 1 Hz 1 Hz Firmware update is running
On On On Firmware update completed successfully
2 Hz On On Firmware update completed with errors
l EDS file defective
l Transmission error
l Flash error
− − Off Fieldbus is offline
l No DC 24V at the fieldbus plug
l No further node at the fieldbus
− − 1 Hz Fieldbus is ready
l No connection established
− − On Fieldbus connected
On − Off Fieldbus error
l Fieldbus address already exists
l Communication error at the fieldbus
On − 1 Hz Inactivity monitoring
− Connection has been terminated due to inactivity
− 1 Hz − System SLIO Bus ready, outputs inactive
− On − System SLIO bus active
On 2 Hz − Access error to system SLIO bus
2 Hz 2 Hz − Configuration error of system SLIO bus
l The numbers of plugged and projected modules are different.
l The module type of at least one plugged module differs from the
parameterised module type.
1 Hz 2 Hz 2 Hz Device error / internal error
Please contact the Lenze service!
"−": Not relevant; "x Hz": Blinking with x Hz
Module status LEDs 0
View Pos. Designation Colour Explanation
1
10
1 PWR IO Green On: I/O supply okay
2 PF IO Red On: Fuse for I/O supply is defective
3 PWR Green On: Electronic supply okay
4 PF Red On: Fuse for electronic supply defective
5
− − Not assigned
6
7
8
9
SLIO001 10
