Product description
Bus coupler modules
PROFINET − EPM−S140
l
51
EDSIO1000 EN 7.0
Module status LEDs
0
View
Pos.
Designation
Colour
Explanation
1
10
1
PWR IO
Green
On: I/O supply okay
2
PF IO
Red
On: Fuse for I/O supply is defective
3
PWR
Green
On: Electronic supply okay
4
PF
Red
On: Fuse for electronic supply defective
5
−
−
Not assigned
6
7
8
9
SLIO001
10
Control elements
Coding switch PROFINET address
3
View
Pos.
Valency
Example
Switching
status
Node address
"1" "0"
1
8
1
−
−
No function
2
1
1
Profinet name: "EPM−S140−xxx"
with xxx = decimal value of position 2 ... 8; for
example: 19
dec
à xxx = 19
3
2
1
4
4
0
5
8
0
6
16
1
7
32
0
SLIO004
8
64
0
Important switch positions
Pos.
Status
Behaviour at restart
2 ... 8
0
Profinet−compliant (IEC 61158−6−10, IEC 61784−2)
l
IP address./subnet mask comes from flash memory.
l
Profinet name comes from flash memory.
2 ... 8
[1 ... 127]
l
IP address./subnet mask comes from flash memory.
l
Profinet name: EPM−S140−xxx (with xxx = decimal value of
position 2...8): Profinet name with I/O controller cannot be
changed.
