PROFIBUS communication
Parameterising the counter
Two counters 32 bits, 24 V DC − EPM−S601
l
439
EDSIO1000 EN 7.0
Lenze
Description/value
Name
Data set
Lenze
Description/value
Name
Byte
No.
2
Comparator
counter 1
Bits 2 ... 0: Comparison bit is set (... if condition is met)
000
b
= never
001
b
= count value
³ comparison value
010
b
= count value
£ comparison value
100
b
= count value = comparison value
Bit 3: Invert counting direction track B
0 = no (do not invert)
1 = yes (invert)
Bits 7 ... 4: Reserved
00
h
3
Signal evaluation
counter 1
Bits 2 ... 0: Signal evaluation
000
b
= counter deactivated (the other parameter
details for the counter are ignored)
001
b
= rotary transducer single (at A and B)
010
b
= rotary transducer double (at A and B)
011
b
= rotary transducer quadruple (at A and B)
100
b
= direction (pulse at A and direction at B)
Bits 6 ... 3: Reserved
Bit 7: Gate function (internal gate)
0= abort (counting process starts again from loading
value)
1 = interrupt (counting process is continued with
counter content)
00
h
81
h
0...3
Set value counter 1
Counting method:
0x3111: byte 3 (high byte)
0x3112: byte 2
0x3113: byte 1
0x3114: byte 0 (low byte)
00
h
4...7
Final value counter 1
Counting method:
0x310D: byte 3 (high byte)
0x310E: byte 2
0x310F: byte 1
0x3110: byte 0 (low byte)
00
h
8...11 Loading value
counter 1
Counting method:
0x3109: byte 3 (high byte)
0x310A: byte 2
0x310B: byte 1
0x310C: byte 0 (low byte)
00
h
12
Hysteresis counter 1
The hysteresis for instance serves to avoid frequent
switching operations of the output and/or triggering of
the alarm when the count value is within the range of the
comparison value. For the hysteresis you can select a
range between 0 and 255. With the settings 0 and 1 the
hysteresis is switched off.
The hysteresis has an effect on the zero crossing,
comparison, overflow/underflow.
00
h
13
Reserved
82
h
0
Alarm response
counter 2
See counter 1
00
h
1
Counter function
counter 2
See counter 1
00
h
2
Comparator
counter 2
See counter 1
00
h
3
Signal evaluation
counter 2
See counter 1
00
h
83
h
0...3
Set value counter 2
See counter 1
00
h
4...7
Final value counter 2
See counter 1
00
h
8...11 Loading value
counter 2
See counter 1
00
h
