Product description
Bus coupler modules
CANopen − EPM−S110
3
l
31 EDSIO1000 EN 7.0
Control elements
The CAN node address and the baud rate are set via the coding switch.
Setting the baud rate:
Coding switch − CAN address and baud rate (addr.) 3
View Pos. Valency
Baud rate
[kbps]
Example
Switching
status
Baud rate
"1" "0"
1
8
1 not assigned − −
2 1 0 = 1000
1 = 500
2 = 250
3 = 125
4 = 100
5 = 50
6 = 20
7 = 10
8 = 800 1
1 + 2 = 3 à baud rate 125 kbps
3 2 1
4 4 0
5 8 0
6 16 0
7 32 0
SLIO004 8 64 0
1. Switch off the voltage supply for the I/O system.
2. Set all switches at the coding switch to "0".
3. Switch on the voltage supply for the I/O system.
The LEDs SF, IF and CAN−RUN are blinking with a frequency of 1 Hz.
4. Set the desired baud rate with the coding switch. You have 10 seconds to do this.
The IF LED goes off after 10 seconds, and the set baud rate is saved.
You have a further 10 seconds time to set the node address.
