CANopen communication
Parameterising the temperature measurement
Four (two) analog inputs for resistance tests − EPM−S404
8
l
302 EDSIO1000 EN 7.0
Lenze Description/value Name Index/sub
index
Channel 4 (for two−wire conductor connections only)
0x3118/x Function channel 4 See channel 1 50
h
0x3119/x Conversion time
channel 4
See channel 1
00
h
0x311A/x Upper limit value
channel 4 (HIGH byte)
See channel 1
7F
h
0x311B/x Upper limit value
channel 4 (LOW byte)
FF
h
0x311C/x Lower limit value
channel 4 (HIGH byte)
80
h
0x311D/x Lower limit value
channel 4 (LOW byte)
00
h
)
Note!
ƒ Use parameter setting to deactivate unused inputs.
ƒ If thermal detectors are connected in a 3 or 4 conductor setup, channels 2
and/or 4 must be deactivated.
ƒ The module does not provide any auxiliary supply for sensors.
